Single Coil Neck pickup resistance: 8.5 kΩ
Single Coil Middle pickup resistance: 8.8 kΩ
Humbucker Low Output bridge pickup resistance: 13.6 kΩ
Single Coil Neck pickup inductance: 3.7 Henries
Single Coil Middle pickup inductance: 3.9 Henries
Humbucker Low Output bridge pickup inductance: 9.4 Henries
Neck pickups pole spacing: 50mm
Middle pickup pole spacing: 52mm
Bridge pickup pole spacing: 53mm
Coil wire: 42-AWG Enamel
Winding: Scatter Wound
Potted: Yes - 20% Bee Wax/80% Paraffin Wax
Single Coil pickup Mounting Screws and Springs: Nickel plated screws and silicone tubing
Humbucker pickup mounting screws and springs: Included (30mm)
Single Coil pickup Hook-Up wire: 25cm pushback cloth wire
Humbucker pickup Hook-Up wire: Shielded 4-conductor Wire (240mm)
* DC Resistance and inductance can differ within 5%.
** For humbucker series wiring, connect WHITE and GREEN wires.
